Complete HD plotting of Roof Truss, Floor Truss, Wall Panels, Floor Cassettes, Wall placements on floors for modular homes, and even virtual walkthroughs.

VersaPlot® is the next step forward in truss projection systems. Imagine projecting to 100% of the table 100% of the time with no flicker, display your paperwork or wall monitor data right on the table, boards up and boards down at the same time, unlimited intersections and graphics all controlled with your smart phone

Our Service

We're Turning Heads With VersaPlot®

Roof Truss Industry

Replacing classic jigging systems to a new and innovative way of setting up your truss tables with this time saving and error reducing technology

Modular Homes

Floor, wall, and truss layouts projected right where you need them


Virtual Walk Throughs

Show detailed floor plans right on the floor in actual size so that customers can walk through and see their design

Exact Plate Placement

With VersaPlot® the plates are placed in the exact location by matching the orientation and location by a picture of a plate in the proper location on the truss joint. This differs from looking at a tiny image projected on a distant screen or TV or a tiny drawing of a plate on a piece of paper.

Train Employees

The entire truss member displayed and labeled. The heel-to-peak measurements are called out on the table at the peak and bottom of the truss and the truss name on the table where new employees can see and use the information. This accelerates training and limits the amount of knowledge they need to remember.

No Flicker

VersaPlot® can display 100% of the truss 100% of the time with no flicker. Lasers need to be eye-safe, so their brightness needs to be limited. Since a laser is a dot, it makes a line by moving the dot quickly in a straight line. The faster the dot moves the shorter the line appears. The more data a laser needs to display the less time a line can be displayed. So, the more complex a display the more the laser line flickers.

Multiple Colors

VersaPlot® uses High Definition projectors so it can display over 16 million different colors all at the same time. This mean it can display several different items in different colors at the same time. No need to turn off plates to reduce the flicker. The plates are displayed in plate color. The jigging layer is one color and the “boards up” is a different color so they can be displayed at the same time without having to switch between them. The multiple layers such as wall components vs wall sheeting positioning can be distinct colors as well. All colors are fully customizable.

Remove Paperwork and Displays

VersaPlot® is designed to eliminate having to refer to monitors or paperwork so all the builders can see the information on the build area where it is useful to everyone at the same time.

No Wasted Time

Save time spent at computer stations. VersaPlot® can be run from smart phones, tablets, or anything with a browser. No need to go to a computer console to call the next truss. Many devices can access the system at the same time, wirelessly.

Auto Calibration

VersaPlot® is the only system that auto calibrates without problematic reflectors needing to be precisely located in the work surface. The auto calibration frequency can be customized, and building can continue through the auto calibration process because the build data remains on the work surface. VersaPlot’s auto calibration uses thousands of calibration points so if one goes missing calibration is not affected.

Much More

Line Thickness
The line thickness can be adjusted to fit you needs without affecting accuracy because the edge of the line is the edge of the board.
Maintenance
The projector boxes can individually lower from the ceiling making maintenance easy and efficient.
Overhead Live View
View production table from any projector to monitor truss assembly and quickly identify problems.
